CVPC Pipe Connector Washing Machine Outlet Box

This product utilizes CPVC solvent-welded joints, achieving molecular-level bonding between pipes and housing through chemical fusion. The conical flow guide design within the joint ensures uniform distribution of welding compound, forming a permanent seal exceeding the strength of the pipe material itself. After curing, the joint strength meets the 2.1MPa burst pressure rating required by the CPVC Schedule 40 standard.

The entire assembly employs CPVC material identical to the piping, eliminating electrochemical corrosion. Pre-installed hot/cold water valve connections are integrally injection-molded, with a 15° angled valve seat for ease of operation. Drain outlets incorporate integrated water seals for odor prevention, while electrical conduit openings feature IP68-rated waterproof sealing. The entire assembly is NSF 61 certified.

Suitable for regions with widespread CPVC piping adoption, such as North America and Southeast Asia. Particularly recommended for hot water systems with long-term operating temperatures ≤93°C and corrosive water environments.

Core Features:
- Molecular Bonding: Solvent welding creates irreversible chemical bonds
- Full System Corrosion Resistance: 100% CPVC construction ensures comprehensive corrosion immunity
- Thermal Creep Resistance: Maintains dimensional stability under continuous 82°C operation
- System Compatibility: Thermal expansion coefficient perfectly matches CPVC piping
